20m - 150m Drilling Depth GXY-1 Spindle Core Geological Drilling Rig Machine

Description:

Hole depth 150M ,GXY-1 core drilling rig, also called exploration drilling rig, water well drilling rig, geological drilling rig, sampling drill, drilling machine, engineering exploration drilling rig, engineering exploration drilling rig, coring rig

Gxy-1 drilling rig is a vertical shaft portable drilling rig produced according to the needs of users. It is suitable for engineering geological exploration, general survey of solid ore deposits, blasting holes and inspection holes of concrete structures.
According to different strata, diamond, cemented carbide, steel sand, screw and other bits can be selected for drilling, and the opening diameter is 150 mm.
When the final diameter of the borehole is 75mm, the depth of the borehole can reach 150m.

Advantages of GXY-1 Geological Drilling Rig Machine

• The drilling rig is equipped with oil pressure feeding mechanism and ball clamping structure, which can realize rod reversing without stopping, with high working efficiency, safety and reliability.
• The drilling rig has high input power, large output torque and strong drilling ability.
• The rig clutch double disc normally closed friction device, borrowed from the mature structure of Dongfeng-12 walking tractor, is flexible in opening and closing, and convenient in use and adjustment.
• The transmission of drilling rig adopts the transmission structure of automobile, with forward and reverse rotation, centralized speed change and interactive self-locking.
• The rotary device of the drilling rig can be unpacked.
• The drilling rig is compact in structure, small in size, light in weight, and easy to disassemble and assemble. It is suitable for working in hilly or mountainous areas.

Specification:

GXY-1 drilling rig is divided into Three Series

The main structure of GXY-1 mobile drilling rig is to change the fixed frame into sliding frame on the basis of gxy-1 type.

The main structure of GXY-1C improved drilling rig is to add high-speed function on the basis of gxy-1.

The main structure of GXY-1C improved mobile drilling rig is to change fixed frame into sliding frame and increase high-speed function on the basis of GXY-1

The main structure of GXY-1A drilling rig is that the fixed frame is changed into sliding frame based on gxy-1 type, and the rotary gear and gearbox are changed into closed type.

The main structure of GXY-1B drilling rig is that the fixed frame is changed into sliding frame on the basis of gxy-1, and the power head is changed from ball chuck to hydraulic chuck.

The main structure of GXY-1C drilling rig is that the fixed frame is changed into sliding frame on the basis of gxy-1 type, the power head is changed from ball chuck to hydraulic chuck and high-speed function is added.

Jinzhou City Shitan Machinery Equipment CO. LTD. is a professional production and

processing company for core drilling rigs, crawler drilling rigs, various track chassis, various

types of mud pumps, various track transport vehicles, etc. It is one of the outstanding

manufacturers of similar products in North China. Strong technical force. The modern production

equipment and complete testing means are specialized in the development, manufacture and

marketing of drilling rigs.

To ensure the quality and stability of the machine, we use the most advanced production and testing

equipment, Made from high quality materials, with fashion and compact design, that keeps our drilling

rigs more efficiency and with low failure rate, more economic and durable, and with a high comprehensive

cost performance. Our water drilling rigs have received the real market validation as the majority of our

customer’s positive feedback.

The company's main products are rigs: XY-1, XY-1A, XY-1B, GK-180, GK-200, DPP-100 and other series

of drilling rigs: gearbox assemblies and gyro assemblies for various rigs, Winch assembly, reducer assembly,

pump assembly. Drilling tools: sedimentary pipe joints, casing joints, casing couplings, drill pipe joints, casing

core pipes, lifters, automatic drop hammers, earth borrowers, standard penetrations, forks, lock joints, alloy drill

bits Hundreds of drilling tools, such as steel sand drill bits, core pipe joints, drill pipe pliers, and casing pliers.

Jinzhou City Shitan Machinery Equipment CO. LTD. has a complete and scientific quality management

system. The integrity, strength and product quality of Jinzhou Stone Exploration Machinery Co., Ltd. have been

recognized by the industry. Welcome friends from all walks of life come to visit, guide and negotiate business!
